  • Heating indoor air mode, can keep heating the room air, and keeps away from any wet or cold or smog air. When people at home or when in the winter morning, just open the room air inlet; when people out or at noon, close the room air inlet and introduce fresh air to ventilate and dehumidify.
    For other models or other brands, the air speed will decrease when air pressure goes up, therefore, the efficiency of heating absorption will decrease. In case you open the window or some other gap to let air go out, but meanwhile, the heat will also be lost. So internal circulation mode is the most suitable for heating room air in the winter or cloudy day.
  • Special heating absorption board: Corrugated special anodic aluminum oxide, texture nano heat insulation coating, high absorption, low reflection. Solar absorbance of selective absorbing coating: 0.92; Hemisphere emittance of selective absorbing coating: 0.12.
  • Solar photovoltaic panels are produced with well-known brand cell in high quality, high photoelectric conversion efficiency, low conversion efficiency attenuation rate, with life expectancy for 20 years. Collectors can be used to dry crops such as vegetables, fruits and grains. The service life of photovoltaic panels will not be affected even under high temperature and strong light in tropical and subtropical regions.
  • Instead of hydraulic fan, double ball fan is adopted, with longer lifespan, low temperature resistant. SUNON from Taiwan is the most well-known fan brand in the world.
  • Under sunlight, the air inside the OS collector flows along both sides of the heat absorbing plate and can absorb the heat well from the absorbing plate. Tested in 900W / m2 sunlight, when the air volume is the same, the temperature of the OS collector is 4 ℃ higher than the collector where air flows only from one side of the heat absorbing plate.

  • Air outlet: it can be opened and closed manually or automatically, with 5mm thermal insulation cotton inside, good insulation effect.  Automatically turns off when the fan is not running.
  • Sealing strips are with high-quality silicone rubber: anti-UV, climate-resistance, better appearance.
  • Frame: exclusively for open air, anti-UV texture coating, anti-UV outdoor screws.
  • Low iron solar tempered glass is with big intensity, high elasticity, the transmission is excellent. Lower diffuse reflection can prevent heat loss.

                                                                        OSCAR Warranty conditions

  • SUNON fan life expectance: 70000 hours; 40000 hours warranty.  Thermostat, air outlet can be replaced free of charge within 2 years.  The lifespan for solar pv panel is 20 years, guaranteed for 10 years. While glass and aluminum materials are with long lifespan.
  • Easy installation, maintenance and operation.
    OS32, OS40/42 can be installed in 2 different directions.

  • Note that by setting up two panels, e.g. one facing east-southeast and one south-southwest, you can take full advantage of the available sunshine throughout the day.
  • Can be installed on the wall or roof without the help of electrician/ construction worker. Small area, light weight. Installing your solar panel is so easy that you can do it yourselves. Product includes thermostat and all the necessary accessories for installation, such as screws, fixing clips, air ducts, air outlets, manuals, etc. Please distinguish wooden house and brick wall, so the correct electric drill is adopted. You can substitute the spare parts except solar pv panels all by yourself within 30 minutes, with easy tools like scissors, tape, screwdriver, etc.
  • Wooden house tools:Heating indoor air mode: when people at home or in winter morning, just open the room air inlet; when people out, close the room air inlet and lead in fresh air to ventilate and dehumidify. If you want a higher heating efficiency, please turn on the air outlet to maximum, heated air losses less if air speed is higher. Please turn down the air outlet, if you need air going to the room with higher temperature. For rooms without good ventilation in winter, we need to turn down the air outlet, so the air pressure will not increase rapidly, then the heated air can be blown into the room easily.
  • Transportation
    If just 1-5pcs samples, it will be cheapest by express to your door. If about 10pcs, we can consider air transport to airport. It usually takes 7-10 days by air to airport or by express. Sea shipping will be much cheaper for larger order quantity. It usually takes 40 days to seaport.
    Unpack the appliance and ensure that nothing is damaged and that all contents are present. If parcel arrives with serious damage, please contact express customer service before receipt, meanwhile please take pictures to retain evidence. In case of loss or damage for air delivery or sea shipment, we recommend ordering insurance. 20pcs/pallets for OS series.
    Regarding the import duty rate, please consult your tax department according to HS code. International Convention for Harmonized Commodity Description and Coding System(HS code)for solar air heater: 8516293100 8419899090 8516299000 8543709990
  • Users’comment
    “After using OS22 air heater, we have cut our family heating bill by as much as 40%” ----Timur Mukhtarov, Russia
    “The performance is unexpected. I actually didn’t expect that much heating effect with such low price! When I put my hand at the air outlet, I can feel the heat and airflow pretty much! Thanks to OSCAR!” ----Alan Marutti, Italy
    “We have saved 430 gallons last year with Oscar solar heater, which cut 35% of our heating bills. It’s really great!” ----Tracey Ahlborn, USA



  • Company introduction
    Oscar Science & Technology Co., Ltd. is a professional manufacturer of solar air collector/ heater, solar ventilator etc.
    We have got China invention patent certificate in April 2014. Patent number: ZL 2012 1 0230757.0. ISO9001 2015 certificate from German TUV NORD CERT since 2018, No.:44 100 1888 0001;
    European Solar Keymark certification (ISO9806), No.:011-7S2867 L; TÜV Rheinland test Report No.: 50152941-001 &50152939-001.
    A developing and testing lab is well established to test air volume, temperature difference of different models in different conditions, also insulation, UV-resistance, climate-resistance, water-proof to various materials such as coating and silicone.
    We have innovatively adopted high-tech material like low iron ultra-pure glass and special texture nano insulation coating etc, and are dedicated to sustainable development and innovations, to ensure good quality and high performance.
    Oscar solar air heaters are sold to many countries like UK, Denmark, Germany, Czech, Australia, New Zealand, Canada, America etc. In the past years, with continuous improvement and innovation, and focus on R&D, quality control, the Oscar solar air heater has won a good reputation due to its high performance and competitive price.


  • Become OSCAR SOLAR Dealer
    To interested dealers / installers:
    OSCAR SOLAR is constantly looking for more dealers / installers around the world. The market for our product is large: not only for holiday homes, but also for many full-year houses, garages, basements, etc., which have problems with the indoor climate and who want to avoid far more expensive solutions, such as heat recovery plants / heat pumps, etc.
    We offer:
    1. Extremely satisfied customers and the opportunity for good earnings, also in the long term. We will fully protect dealers' profits, create an independent brand: OASES SOLAR, sell strictly according to website prices (www.solaroases.com ), and allow distributors to set their own prices and set up their own websites and brands locally.
    2. Practical help with marketing. We will add the distributor's contact information and address on the website (www.solaroases.com). Consumers can easily contact nearby dealers. Can be translated into native language through Google Translate plugin.
    3. If order quantity is more than 50pcs, we may give 5% discount. If order quantity is more than 100pcs, 8% discount. If order quantity is more than 200pcs, 12% discount.
    4. For most customers in the European Union, the goods can be delivered to your door with very low freight, including customs clearance fees and duties, as long as payment is made 2 months in advance. Even if it's 2 units, the freight is just 90USD for 1pc
    OS20/22; the freight is just 1pc 140USD for OS30/32. A discount is also available for large quantities purchased at one time.
    5. High solar subsidy from www.bafa.de for OS22, OS32, OS42 in Germany. OS22 can get a basic subsidy of 140.00 euros; OS32 / 42 can get a basic subsidy of 280.00 euros. The application for the models is quite simple and can be done online.
    6. US warehouses and Australian warehouses are also planned, and customers in the Americas and Australia can purchase at very low shipping rates, as long as they book in advance.
    7. It is even possible to store the goods in our warehouse in Germany and send the goods directly to the customer's house. If the ordered goods can't be sold, OSCAR SOLAR can buy them back at a 30% discount.
    We require:
  • Please inform us of the population and area of the distribution area, planned sales volume, number of in-channel sales outlets, Capital investment plan, marketing promotion plan, advertising plan, etc.
  • Please let us know your requirements, such as advertising, how to protect your sales and profits, etc.


  • High solar subsidy from www.bafa.de for OS22,OS32,OS42 in GermanyOS22 can get a basic subsidy of 140.00 euros; OS32 / 42 can get a basic subsidy of 280.00 euros. The application for the models is quite simple and can be done online.

Important: The application and receipt of the corresponding confirmation of receipt must be made before the purchase.

The application can be found on:



Und so einfach kommen Sie an die Förderung:

1. Antrag passend zur Kollektorfläche des gewählten stellen. Die Basisförderung beträgt aktuell EUR 140,00 pro angefangenem Quadratmeter Bruttokollektorfläche. 2. Im Normalfall erhalten Sie nach dem gestellten Antrag (einfach mit dem Online-Formular auf der BAFA Homepage) die Eingangsbestätigung mit einer Internet- ID Nummer direkt per E-Mail zurück und können dann beruhigt den Kauf fortsetzen. 3. Gewünschtes Set bestellen, Inbetriebnehmen und die Rechnung einreichen. Die Rückvergütung erhalten Sie dann auf Ihr Konto überwiesen.
